How to Update CWWK BIOS Using Ventoy

Quick Answer

Most of our BIOS firmware is provided in the form of an ISO file, and it can be updated using a Ventoy bootable USB drive within the UEFI environment.

The basic process is:

Download Ventoy → Create a bootable USB drive → Copy the BIOS ISO to the USB drive → Boot from the USB drive → Verify the BIOS information → Start the update → Restart and check the BIOS version.

This guide demonstrates how to create a Ventoy bootable drive using a Windows computer. The ISO-based update process follows the same overall steps.

Step 1: Download Ventoy

Ventoy is a bootable USB utility that allows ISO files to be launched directly from a USB drive. It can also be used with installation images such as ESXi, Proxmox VE, Windows, and Linux.

1.Go to the Official Ventoy Website:
https://www.ventoy.net/en/index.html

Click on the latest Ventoy version below the News title.

2.Then select the "windows.zip" version for download. After approximately 5 seconds, the download will start automatically.

3.Wait for the download to complete.

The version number may change as Ventoy is updated, so it does not need to match the version shown in the screenshots.

Step 2: Create a Ventoy Bootable USB Drive

After downloading Ventoy, extract the ZIP file completely.

Open the extracted folder and locate:

Ventoy2Disk.exe

Run the program, then:

1. Select your USB drive under Device.
2. Check the drive letter carefully.
3. Click Install.
4. Confirm the operation when prompted.
5. Wait for Ventoy to finish installing.
6. Close the program after the success message appears.




Important: Check the selected drive carefully before clicking Install to avoid selecting the wrong storage device.

Step 3: Copy the BIOS ISO File to the USB Drive

After installing Ventoy, directly copy the CWWK BIOS ISO file to the USB drive.
After the file is copied, safely eject the USB drive and connect it to the CWWK device that needs BIOS update.

Step 4: Record the Current BIOS Information

Turn on or restart the CWWK device and repeatedly press:

Delete

until the BIOS Setup screen appears.

Before updating, take a photo or make a note of the current BIOS information.

You can compare this information with the new BIOS version after the update is complete.

Step 5: Boot from the Ventoy USB Drive

In the BIOS, open:

Save & Exit

Find the Boot Override section and select the USB boot device.

Depending on the USB drive and motherboard, it may appear as:

UEFI: USB

or under the USB drive's brand or model name.

Select the USB drive and press Enter. The device will then boot into Ventoy.

Step 6: Select the BIOS ISO File

After entering the Ventoy menu, you should see the BIOS ISO file stored on the USB drive.

Use the arrow keys to select the BIOS ISO and press Enter.

On the next screen, choose:

Boot in normal mode

Press Enter again to launch the BIOS update environment.

Do not select a BIOS file if you are unsure whether it belongs to your device.

Step 7: Verify the BIOS Information

After the update program starts, press Enter before the countdown ends.

The screen will display information about the BIOS package.

Check the displayed information carefully.If the information matches your device, press Enter to continue.

This is the final verification before the BIOS is written. The CWWK BIOS update manual specifically instructs users to check the model information and confirm that the correct BIOS ISO has been placed on the USB drive.

If the model information does not match, stop the update.

Step 8: Start the BIOS Update

After entering the BIOS update interface, you may need to press Enter again to complete the final confirmation.

The flashing process will then begin automatically.

During the update, you may see messages such as:

Erasing Flash Block
Programming Flash
Processing Flash Memory Block

These messages indicate that the BIOS firmware is being written.

While the update is running:

• Do not turn off the device.
• Do not force a restart.
• Do not remove the USB drive.
• Do not exit the update program.
• Do not interrupt the flashing process.

Step 9: Confirm That the BIOS Update Is Complete

When the flashing process finishes, the screen should display a successful completion message.

For example:

FPT Operation Successful

Once the success message appears, follow the on-screen instructions and press Enter.

Do not shut down the device while the BIOS is still being erased or programmed.

Step 10: Wait for the Device to Restart

After the BIOS update is completed, press the Enter key and let the device restart.

The system usually restarts twice:

The first restart is used to record hardware information;
The second restart will normally start the system.

The first startup after the BIOS update may take longer than usual. Please wait for the process to complete and do not forcefully shut down or force the device to restart.

Step 11: Verify successful boot

If you previously set the USB drive as the first boot option, the second restart will directly enter the Ventoy menu again. This indicates that the system has successfully booted.

Step 11: Verify the New BIOS Version

After the device restarts, repeatedly press Delete again to enter BIOS Setup.Compare the new information with the BIOS details recorded before the update.

If the BIOS version or build date has changed to the expected version, the update has been applied successfully.

FAQ

Does the BIOS ISO File Need to Be Extracted?

No. Copy the complete BIOS ISO file directly to the Ventoy USB drive.

Why Can't I See the BIOS File in Ventoy?

Check that the BIOS file was successfully copied to the USB drive and that it still uses the .iso file extension.

Should I Select Boot in grub2 Mode?

The CWWK manual uses Boot in normal mode. Unless the BIOS package includes different instructions, use the normal boot mode.

Is It Normal to Press Enter Several Times During the Update?

Yes. You may need to press Enter when selecting the ISO, entering the BIOS update interface, and confirming the firmware before flashing begins.

Always read the information on the screen before continuing.

Can I Remove the USB Drive During the BIOS Update?

No. Keep the USB drive connected until the BIOS update is complete and the device has finished restarting.

Why Does the First Boot Take Longer After a BIOS Update?

The first restart may take additional time because the system needs to record and initialize hardware information after the firmware update.

Does Returning to the Ventoy Menu Mean the BIOS Update Failed?

Not necessarily. If the USB drive is still the first boot device, the computer may simply boot into Ventoy again.

Remove the USB drive or restore the original system drive as the first boot option.

What If You Cannot Find the Correct BIOS File?

Before contacting support, check the CWWK Technical Documentation Center to see whether a BIOS file is available for your product model.

Search using the full product or motherboard model whenever possible, and make sure the BIOS file matches your device before downloading it.

If you cannot find the correct BIOS file in the Technical Documentation Center, contact CWWK after-sales support for assistance.

To help the support team identify your device more quickly, provide:

• Order number or a screenshot of the order
• Full product model
• Motherboard model, if available
• Photo of the product or motherboard label
• Current BIOS version, if available
• A short description of the issue

The support team can then help confirm the correct BIOS file for your device before you begin the update.
